| Module |
| 1 | Pixel pitch | PH5 |
| 2 | Resolution | 40000 dots/sq.m |
| 3 | LED composition | 1R 1G 1B |
| 5 | Module size(mm) | W160*H160 |
| 6 | Module resolution | W32*H32 |
| 7 | Module quantity | W6 *H2= 12pcs *2(double side)=24pcs |
| Cabinet |
| 9 | Cabinet size(mm) | W960*H320 (not including the bracket height) |
| 10 | Cabinet resolution(dots) | W192*H64 |
| 11 | Cabinet quantity(pc) | 1 |
| 12 | Cabinet material | Aluminum cabinet |
| 13 | Cabinet color | black, silvery, custom-made |
| 14 | Cabinet weight(kg/pc) | 21KG |
| 15 | power consumption(w) | 750W |
| Package |
| 16 | Packaging Size(m)(per pc): | W1050*H510*D340 |
| 17 | Package Material: | ply wooden case |
| 18 | Wooden Case Quantity(pcs): | 1 |
| 19 | Inner Pack: | EPE foam |
| 20 | G.W.(kg): | 45KG |
| Viewing |
| 21 | White Balance Brightness(cdm) | ≥4500 |
| 22 | Display Color grade | 256 grade, ≥16.7 M colors |
| 23 | View Angle | Horizontal 140°; Vertical 20° |
| 24 | Min. viewing distance(m) | 5 |
| 25 | Max. viewing distance(m) | 50 |
| Driving method & scan |
| 26 | Driving Method | 1/8 scan Constant driving current |
| 27 | lED lamp | Silan /Opto |
| 28 | Refresh Frequency (Hz) | ≥500 |
| Control system & connector |
| 29 | display system control method | Asynchronous control |
| 30 | video format | AVI,WMV,MPG,MOV,DAT,VOB,MP4,FLV.ect |
| 31 | pictuer format | GIF,SWF,bmp,jpg,gif,wmf,ico,ect |
| 32 | words format | txt,rtf,ect |
| 33 | Input signal | Video: PAL/NTSC Option: VGA , Video , DVD,TV, etc |
| 34 | Software | Window xp /Vista/ win7/win8 |
| 35 | Communication distance(m) | Internet Wire<100, fiber>100 |
| 36 | Supported Networking | Through LAN/ WAN, RS232/RS485 |
| Protect & maintain |
| 37 | Protection grades | IP65 |
| 38 | Working temperature(ºC) | -20~+60 |
| 39 | Humidity(RH) | Up to 95 |
| 40 | Display Lifetime(50% brightness, hours) | ≥100,000 |
| 41 | Out of controlled dot | ≤1/10,000 |
| 42 | Whole Display Flatness | Less than 1mm Juncture |
| 43 | Operating Voltage | DC-12V car power supply, or 220°C±10% or 110°C±10% |
| 44 | Maintenance way | middle, displace module |
